7 Wire Prestressing Concrete Steel Strand

Categories

7 Wire Prestressing Concrete Steel Strand

Categories	PC Strand
Album	View larger image
Brand	ZHONGCHI
Model	PS03
Weight per coil	at your request
Packing	standard export packing
FOB port	Tianjin Port,China
Terms of Payment	L/C, T/T
Update Time	2020-01-23

Contact Now

Favorites

Detail Information

7 Wire Prestressing Concrete Steel Strand

PC strands consists of wires spun together in the same direction and with the same lay length. PC strands product contains 2-wire, 3-wire,7-wire and 19-wire strands. Low relaxation PC strand can be used for either prestressing or post-tensioning of concrete.

Feature: Low relaxation, High Tensile Strength, Straight,
1) Construction: 2, 3, 7,19 wire
2) Standards: GB/T5224-2003, BS5896-1980, EN10138-2005,AS NZS 4672.1-2007, ASTM 416-2006, ISO_6934-4-2000, JIS G 3536-1999, etc...

Packing details:
Coils are wrapped by 8 steel strips
Wrapped by waterproof cloth
Added with wood pallet or according to customer's requirements

Commodity	PC strands
Steel grade	82B
Standards	GB/T5224-2003, BS5896-1980, EN10138-2005,AS NZS 4672.1-2007, ASTM 416-2006, ISO_6934-4-2000, JIS G 3536-1999, etc...
Tensile strength	1470-1860MPa
Diameter	6.2-17.8mm
Applications	used for prestressed concrete structural reinforcement, such as span railway and highway bridges, crane beam, ground anchoring project, multi-storey industrial plants and other.
Technique	Cold drawing
Packing	Bundled by steel strips,Coils are wrapped by 8 steel strips Wrapped by waterproof cloth Added with wood pallet or according to customer's requirements
Surface	Helix (screw/spiral), plain, indented
